Capacity
Swing over bed mm: 720
Between centers mm: 604
Max. turning dia. mm: 390
Std. Turning dia. mm: 320
Bar capacity mm: 52 (opt. 66)


Axis Feeds
X axis travel mm: 195+20 (160+50)
Z axis travel mm: 600
E axis travel mm: 550
Rapid feedrate m/min: X/Z: 24/24 (E:15)
Feed servo motor KW: X:3, Z:4 (E:2.5)
JOG feedrate mm/min: X/Z=0~1260
Ballscrew dia. x pitch mm: Ø32×P6 (X), Ø40×P8 (Z), Ø40×P8 (E)

Spindle
Max. spindle speed rpm: 4200 (belt-driven)
Spindle nose (chuck) Inch: A2-6 (8”)
Spindle bore Mm: 62 (opt. 76)
Spindle motor (cont./30min) KW: 7.5/9 (αiIP15)
Bearing inside dia. mm: 100 (opt. 120)


Sub-spindle (E axis)
Max. spindle speed rpm: 7000 (built-in)
Spindle nose (chuck) inch: A2-5 (5”)
Spindle motor (cont./25%) KW: 7.5/11 (Bil112S)
Bearing Inside dia. mm: 75
Spindle bore mm: 42
Bar capacity mm: 30

Turret
No. of tools no.: 12
Tool shank size mm: 20 (opt.25)
Max. boring bar dia. mm: 40
Exchange time (T-T) sec: 0.3
Exchange time (incl. turret disk up & down) sec:1.04 (Adjacent), 1.45 (opposite)

Tailstock
Quill diameter mm: N.A. (digital)
Quill taper     MT#4
Stroke (E-axis) mm: 550

Accuracy
Positioning accuracy (bi-directional) mm: 0.01
Repeatability mm: ±0.004

Machine
Coolant tank capacity L.: 330
NC controller Fanuc 0i-TF Plus (10.4”)
Power requirement KVA: 21 (28)
L×W×H (with chip conveyor) mm: 3882 x 2430 x 2056
Net weight        kg: 6500 (6700)
