Specifications

Capacity
Swing over bed: 600 mm
Swing over carriage: 540 mm
Max. turning length: 520 mm
Std. turning diameter: 470 mm

Travel
X-axis stroke: 280+130 mm
Z-axis stroke: 540 mm

Spindle
Max. spindle speed: 2500 rpm
Spindle nose: A2-8
Spindle bore: 86 mm
Inner bearing: 130 mm
Chuck diameter: 12" (Optional: 10", 15", 18")
Max. part weight (incl. chuck): 593 kg

Turret
No. of tools: 8
No. of live tools (optional): 8 (VDI-40, DIN-5482, axial type, left-hand)
Tool shank size: 32 mm
Max. boring bar diameter: 50 mm
Exchange time: 1 sec (hydraulic)

Feedrate
Rapid feedrate: X/Z = 15/24 m/min
X-axis ballscrew: Ø50 × P10 (moving column)
Z-axis ballscrew: Ø40 × P12
Cutting feedrate: X/Z = 0~1260 mm/min

Motor
Spindle motor: 15/18.5 kW (αP30i) (Optional: 18.5/22 kW (αP40i))
Gearbox: Optional
X/Z axis servo motor: X: 4 kW, Z: 4 kW
Milling motor (optional): 4 kW

Machine
Fanuc controller: 0i-T
Coolant tank: 185 L
Dimensions (W × L × H, including chip conveyor): 1560 × 3250 × 2918 mm
Power requirement: 40 kVA (Optional: 45 kVA for CV)
Net weight: 6000 kg
