Capacity
Swing over carriage dia: Ø600 mm
Standard turning dia: Ø480 mm
Maximum turning dia: Ø580 mm
Max. turning length: 1298 mm
Main Spindle
Max speed: 2500 rpm
Nose (chuck): A2-11 (12")
Bar capacity: Ø91 mm
Turret
No. of tools (live): 10 T
Shank size: □32 mm
Tailstock
Quill taper: M.T. #5
Machine
Weight: 9850 kg

Standard accessories

Fanuc 0i-TF(8.4”) with Manual Guide 0i
Hydraulic chuck with soft jaws
Programmable tailstock
Chip conveyor
Fully enclosed splash guarding
Hand wheel
Tool holders (for standard turret only)
Coolant flush on Z-axis cover
3 step warning light
