Swing over bed:    25.98”
– Swing over carriage:    17.52”
– Swing over gap:    35.12”
– Width of gap in front of face plate:    10.63”
– Distance between centers: 118”
– Width of bed:    15.75”
– Stroke of tool post:    9.53”
– Stroke of cross slide:    15.75”
– Spindle bore:    4.09”
– Taper of spindle bore & center:    MT#7 & MT #5
– Spindle nose:    D1-11
– Number of spindle speeds:    12
– Spindle speed:    13, 20, 30, 47, 70, 105, 150, 230, 340, 530, 800, 1200 rpm
– Number of feeds:    36
– Range of longitudinal feeds:    0.037~1.04mm/rev (P=6 mm, 12mm); 0.035~0.98mm/rev (4 TPI, 2TPI)
– Range of cross feeds:    ½ of longitudinal feeds – Lead screw diameter: 1.77”
– Lead screw pitch:    4TPI, P=6mm (2TPI, P=12mm)
– Range of inch pitches:    2~72 TPI / 44 kinds (1~42TPI/ 48 kinds)
– Quill stroke:    7”
– Quill diameter:    2.95”
– Quill taper:    MT #5
– Main motor:    15 HP/ 4P
– Coolant pump motor:    ⅛ HP
– Machine height:    60”
– Floor space: 178”
– Weight: 6,930 lbs.

Standard Accessories:
– Multi-position length stop
– 12” drive plate
– Center sleeve MT # 7 x 5
– Service kit
– Dead center MT# 5
– Coolant system
– Leveling screws
– Steady rest 1.57”~10” with roller jaws
– Full length splash guard
– Pull Drawer Chip Pan
– 15 HP/4 P main motor
