The Nicolás Correa L30/104 is a powerful horizontal CNC boring mill engineered for large-part machining. Featuring 10,000 mm (393") of X-axis travel, 1,250 mm (49") Y-axis, and a massive table capacity of up to 44,000 lbs, this machine is designed for demanding applications. Equipped with a Heidenhain CNC control, automatic tool changer, ISO 50 spindle taper, and heavy-duty box ways, it delivers reliable performance in large-scale manufacturing and repair work.


Technical Specification – Nicolás Correa L30/104
Model: Nicolás Correa L30/104
Manufacturer: Nicolás Correa S.A., Spain
Serial Number: 790241
Year of Manufacture: 05/2004
Control System: HEIDENHAIN CNC

X-Axis Travel: 10000 mm (393")
Y-Axis Travel: 1250 mm (49")
Z-Axis Travel: 1500 mm (59")
W-Axis (quill travel): approximately 500 mm (20")
Table Size: approximately 1250 mm x 10000 mm (49" x 393") with T-slots
Max Table Load Capacity: approximately 20000 kg (44000 lbs)

Spindle Diameter: approximately 130 mm
Spindle Speed: up to 3000 RPM
Spindle Taper: ISO 50
Main Spindle Motor Power: up to 40 kW
Automatic Tool Changer: rotary type

Voltage: 400 V
Frequency: 60 Hz
Phase: 3-phase
Rated Capacity: 58 kVA
Full Load Current: 84 A
Largest Motor Load: 72 A

Full enclosure with safety doors
Automatic tool changer arm
Coolant system
Chip conveyor
HEIDENHAIN control with manual and CNC modes
Box ways and heavy-duty bed construction for large workpieces

Approximate Weight and Dimensions
Weight: ~55,000 kg (121,000 lbs)
Length: ~14,000 mm (14 m / 46 ft)
Width: ~5,000 mm (5 m / 16.4 ft)
Height: ~3,500 mm (3.5 m / 11.5 ft)
