• Platform Height: 26ft
• Horizontal Outreach: 9ft
• Up and Over Height: 22ft
• Swing: 360° (Non-continuous)
• Max Capacity: 500 lbs
• Platform: 27.5" x 35.4"
• Stowed Height: 6ft 6"
• Stowed Width: 39"
• Stowed Length: 9ft 7"
• Tailswing: 4"
• Wheel Base: 4ft 3"
• Weight: 6000lbs
• Ground Bearing Pressure: 178psi
• Ground Clearance: 3"
• Drive Speed Stowed: 4.0 km/h
• Drive Speed Elevated: 0.7 km/h
• Gradeability: 20%
• Tire Size: 16 x 5 x 10.5
• Turning Radius (Inside): 0"
• Turning Radius (Outside): 5ft 9in

• Battery: 24V, 620A-hr
• Battery Charger Output: 55A
• Brakes: Spring Applied
• Certification: Yes

• Vertical telescopic mast with a jib for tighter spaces
• Non-marking tires and electric powered
• Extremely compact equipment
• 110V-AC Receptacle in the platform
• Emergency Lowering Pump
• 5° Tilt Alarm/Indicator Light
• Dual Warning Beacons
• All Motion Alarm
• Lifting Eyes
• Tie-Down Lug
• Proportional Controls

• For Rent Use: In-door only
• No additional fees just GST

• Daily Rate: $195
• Weekly Rate: $790
• Monthly Rate: $1750
• Refundable Deposit: $2000

• $150 Roundtrip (Edmonton, Devon, Beaumont)
• $200 Roundtrip (Spruce Grove, Fort Saskatchewan, Stony Plain)
